The Smart Powered Hub combines a passive RS-485 hub with an integrated 24 VDC power supply in a single weatherproof enclosure. It provides six RS-485 inputs and one output for connecting multiple smart instruments to a data logger or control system, while also supplying up to 2.2 A of 24 VDC power for connected devices.
Features
- Connects up to 6 smart instruments via RS-485
- Integrated 100–240 VAC to 24 VDC power supply (2.2 A max)
- IP65 weatherproof housing
- 6 RS-485 inputs and 1 RS-485 output
- RS485-surge suppressors
Presupuesto
-
Atributos técnicos
| 24 x 18 x 9 cm | |
| Montaje en poste | Kit de montaje en poste, 0,7 kg (embalado) |
| Peso | 1,4 kg |
| Fuente de alimentación | 100–240 V, 47–63 Hz, máx. 2 A |
| Potencia de salida | 7 x 24 V ± 1 V, máx. 2200 mA en total |
| Temperatura | De -20 a +50 °C (funcionamiento) |
Resources
+
Manuales (1)
3303096
Kipp & Zonen LOGBOX SE Data Logger
